Heat-lacquered steel

Company:

Category:

Non-alloy structural steels are iron-based materials with a low carbon content. Thanks to their low cost and good mechanical properties, they are widely used in the steel and mechanical engineering industries. These types of steel account for over 90% of total production in the sector, demonstrating their industrial importance.

They are commonly sold in the form of bars or profiles, obtained by hot rolling or cold drawing. In terms of properties, they are ductile, easy to work with, flexible and strong. However, they cannot be hardened. Interestingly, as the carbon content increases, so do the hardness and strength of the material.

Thanks to their low cost and characteristics that are more than adequate for numerous applications, non-alloy steels are often used in the manufacture of components for machinery and metal structures, provided that no special heat treatments are required. These are simple materials, but nevertheless reliable for many common uses.

Steel is made from cast iron, an alloy containing up to 4% carbon along with other unwanted or excess elements such as silicon, manganese, sulphur and phosphorus. Cast iron is transformed into steel through a process called “refining”, during which the carbon content is reduced and impurities are almost completely eliminated. This process is followed by further treatment to improve the final quality of the material.

Thermal lacquering, also known as powder coating, is a technique used to coat metal surfaces with thermosetting powders. This treatment provides effective protection against corrosion and gives a more attractive appearance. When applied to steel, thermal lacquering produces a solid and durable finish, suitable for both industrial and decorative purposes.

At the end of its life, steel is recovered, sorted by type, remelted and reused to create new products. Finally, it is important to remember that non-alloy construction steel is subject to corrosion (rust) and has a rather limited heat resistance.

Main source of description

Material-Archiv. (2024). Baustahl, unlegiert.

Material

Steel

Usage

Horizontal load-bearing structure, Oblique load-bearing structure, Vertical load-bearing structure

Property

Compact, Rigid

Shape

Irregular, Sheets

Sample

1

Sample ID

EM000009402249

Place

wall C

Sample weight

1000g – 5000g

Density

7850 kg/m3

Modulus of elasticity

212000 N/mm2

Tensile strength

310-680 N/mm2

Thermal conductivity coefficient

48-57 W/mK
